Part Number: FMA12-4.00”-B1.25”-ON08-07
Dimension (inch): ΦD=4.000, ΦD1=4.591, Φd=1.250, L=2.500, ap (max)=0.197
Mounting Type: B
Number of Teeth (Z) = 7
Kr = 45°
Associated Inserts: ONHU08T624R-GM (compatible with ONHU08T508-PM and ONHU08T508-PF with the same ap(max) value)
Associated Accessories: Insert Screw I60M5x13, Wrench WT20IT
Note: Milling cutter sold without inserts. Insert screws and torque wrench included.
