FMA12-8.00"-C2.50"-ON08-12

FMA12-8.00"-C2.50"-ON08-12
Item# CM-4350002470
$725.00
Availability: Usually ships the same business day

Product Description



Part Number: FMA12-8.00"-C2.50"-ON08-12

Dimension (inch): ΦD=8.000, ΦD1=8.591, Φd=2.500, L=2.500, ap (max)=0.197

Mounting Type: C

Number of Teeth (Z) = 12

Kr = 45°



Associated Inserts: ONHU08T624R-GM (compatible with ONHU08T508-PM and ONHU08T508-PF with the same ap(max) value)

Associated Accessories: Insert Screw I60M5x13, Wrench WT20IT

Note: Milling cutter sold without inserts. Insert screws and torque wrench included.
